LangGraph from Scratch, Part 2: FastAPI Fundamentals

Your backend has been keeping a secret. Since the moment it first started in Part 1, FastAPI has been maintaining a second page you never wrote: a live, clickable control panel for your API. It sits at http://localhost:8000/docs, and it has been waiting there this whole time.

Today it earns its keep. You'll teach the backend to accept a chat message and answer back, crash it with a one-letter typo, then teach it to reject that same typo with an error so precise it names the field. By the end, this is your screen:

One honest note before we start: there is no LangGraph in this part, on purpose. Part 3 hands the conversation to a real language model, and every concept here (request shapes, validation, the docs page) is load-bearing for that. If you already know FastAPI and Pydantic, skim the headings, copy the final main.py, and meet me at the commit.

Three versions matter today, all of them already on your machine since Part 1's big pip install:

Pydantic is the new name on the list, but not new in your .venv; it rode in with FastAPI. You'll meet it properly in a few minutes.

Wake the backend up

New day, fresh terminal, and a reflex to practice. Open a terminal, cd into langgraph-chatbot/backend, and look at the prompt. No (.venv)? You know this one now:

source .venv/bin/activate
uvicorn main:app --reload

(On Windows the first line is .venv\Scripts\activate, as always. And if Part 1's server is somehow still running in an old terminal, that window works as-is; don't start a second one, or the two will fight over port 8000.) The frontend stays asleep today; this whole part lives on the backend.

With the server running, open the address from the intro: http://localhost:8000/docs.

The page you never wrote

This is Swagger UI, an industry-standard API explorer, and FastAPI built it by reading your code. Your eight-line main.py contains everything needed: the route (/), the method (GET), even the human label, which FastAPI made by title-casing your function name health_check. The /openapi.json link at the top is the machine-readable description it generated first; this page is that description, rendered.

That's the FastAPI trade in one screen. You write plain typed Python, and the framework derives three things from it: documentation (this page), validation (the star of today), and serialization (your dicts becoming JSON in Part 1). Change the code and all three update; this page never goes stale.

It can also send real requests, which makes it the best debugging tool you'll have all series. We'll push its buttons once there's something worth pushing.

One file becomes a folder

A confession about where we're heading: by Part 6 the backend will be main.py plus graph.py plus tools.py. Three loose files rattling around next to .venv and .env gets confusing, so Python projects put application code in a package: a folder of related modules. We'll make that folder now, while moving one file is cheap.

First, stop the server: click into its terminal and press CTRL+C.

Now, in your editor's file tree, inside backend/: create a folder named app, create an empty file named __init__.py inside it, and drag main.py in as well. (Terminal equivalent on macOS/Linux: mkdir app && touch app/__init__.py && mv main.py app/.) The result:

backend/
├── .venv/
├── .env
└── app/
    ├── __init__.py
    └── main.py

The file moved, so the old uvicorn main:app is now pointing at nothing. If muscle memory runs it anyway, the error is refreshingly direct:

ERROR:    Error loading ASGI app. Could not import module "main".

There is no module named main at the top level anymore; it lives inside app now. So the new launch command, from backend/ as always:

uvicorn app.main:app --reload

Same dotted logic as Part 1, one level deeper: "in the package app, in the module main, find the object app." Run it, check http://localhost:8000 still says {"status":"ok"}, and update your reflexes: this is the launch command for the rest of the series.

Checkpoint. Right now you have: the same one-endpoint API, in a package with room to grow. Same behavior, better bones.

Teach it to listen

GET / answers anyone who knocks, but it can't receive anything. A chat endpoint has to accept the user's message, and in HTTP that means a POST request carrying a body. Open app/main.py and add a second endpoint below the first:

@app.post("/chat")
async def chat(payload: dict):
    return {"reply": f"you said: {payload['message']}"}

Two new things, one deferred mystery. @app.post("/chat") is the same decorator pattern as Part 1, for POST requests. payload: dict tells FastAPI "the request body is JSON; parse it into a dict for me." The mystery is async; it gets its own section soon, and changes nothing about today's behavior.

Save the file and glance at the server terminal:

WARNING:  WatchFiles detected changes in 'app/main.py'. Reloading...

That's --reload earning its keep, exactly as promised in Part 1. No restart, ever.

Your browser can't easily send a POST (the address bar only speaks GET), but your terminal can. curl is the command-line tool for making HTTP requests, and it's how we'll poke every backend feature until the frontend exists. Open a second terminal (any terminal that isn't hosting the server; curl needs no (.venv)) and send your backend its first message:

curl -X POST http://localhost:8000/chat -H "Content-Type: application/json" -d '{"message": "hello"}'

{"reply":"you said: hello"}

It listens!

Now break it on purpose

In Part 4, a frontend will send that exact request from code, and code gets field names wrong constantly. So send the typo today, deliberately, while the stakes are zero. One letter: message becomes mesage.

curl -X POST http://localhost:8000/chat -H "Content-Type: application/json" -d '{"mesage": "hello"}'

Internal Server Error

Three words and no clues; that's what the caller gets. The real story landed in the server's terminal:

Read it bottom-up, like every traceback: KeyError: 'message'. The line above shows the scene of the crime, your f-string reaching for payload['message'] in a dict that only has mesage. Plain Python dict, missing key, crash.

Sit with what happened, because it's a pattern you'll meet for years. The endpoint trusted its input. One typo'd field from one caller, and your code threw an uncaught exception; FastAPI converted the wreckage into a 500 Internal Server Error, which is HTTP for "not your fault, dear caller, mine." Exactly backwards here: it was the caller's typo, and they're the one person the message tells nothing.

This bug has a long career. Somewhere right now an API is returning 500s because a mobile app sends userID and the server expects user_id, and the developer staring at this same traceback has a pager going off. The fix was never "more careful callers." It's a stricter door.

The kitchen gets an order form

FastAPI's door is Pydantic: a library that lets you declare the shape of your data as a Python class, then checks every incoming request against it before your code runs. You met type hints on payload: dict; Pydantic is what happens when the hint gets specific. Replace the whole of app/main.py with this:

from fastapi import FastAPI
from pydantic import BaseModel

app = FastAPI()


class ChatRequest(BaseModel):
    message: str


class ChatResponse(BaseModel):
    reply: str


@app.get("/")
def health_check():
    return {"status": "ok"}


@app.post("/chat")
async def chat(request: ChatRequest) -> ChatResponse:
    return ChatResponse(reply=f"you said: {request.message}")

ChatRequest is an order form: one required box, message, which must hold a string. Swapping the parameter to request: ChatRequest is the entire enforcement step; FastAPI reads that type hint and builds the door check from it. The hint isn't decoration anymore. It's load-bearing.

ChatResponse does the same for the way out: the return annotation declares what /chat promises to send back, documents it, and would strip any extra fields you accidentally included. In and out, both shapes are now contracts.

The server has already reloaded. Send the same typo'd request again, and this time the response is worth pretty-printing (curl hands it to you on one line):

curl -X POST http://localhost:8000/chat -H "Content-Type: application/json" -d '{"mesage": "hello"}'

{
  "detail": [
    {
      "type": "missing",
      "loc": ["body", "message"],
      "msg": "Field required",
      "input": {"mesage": "hello"}
    }
  ]
}

Same typo, different universe. The status code is 422 Unprocessable Entity, which means "I understood the request; its contents don't match the contract." And look at what the caller receives now: which field (message), where it was missing from (the body), what the rule was (Field required), and an echo of what they actually sent, typo visible. Your function never ran. The kitchen rejected the order form at the window, and it circled the empty box.

The docs got smarter while you weren't looking

Refresh http://localhost:8000/docs:

Before the models, this page described /chat's request body as {"additionalProp1": {}}, the OpenAPI equivalent of a shrug: "sends... something." Now it knows the exact shape in, the exact shape out, and it documents the 422 you just earned, because every Pydantic-validated endpoint can produce one. Scroll down and your own classes, ChatRequest and ChatResponse, have a Schemas section to themselves.

And now the buttons are worth pushing. Expand POST /chat, click Try it out, change the example body's "string" to real words, and hit Execute. The response appears right in the page; that's exactly how the screenshot at the top of this part was made. Two details worth noticing while you're in there: Swagger shows you the precise curl command it ran (compare it to yours), and for Windows readers this button is the JSON-quoting-free way to test everything from here on.

So what is async def?

Time to close the loop from earlier. async def makes a function pausable: when it hits a slow operation that supports it (a database read, an LLM call over the network), it can step aside and let the server handle other requests while it waits, instead of blocking the whole process. That single idea is why Part 1 installed uvicorn, a server built around this kind of cooperative waiting.

For today's echo there's nothing to wait for, so async changes nothing observable. The payoff is scheduled: in Part 3 this endpoint will spend whole seconds waiting on a language model, and in Part 5 it will stream a reply word by word, a trick built entirely out of this kind of pausing. Writing the endpoint async from day one means neither part needs a rewrite.

One locked door between you and Part 4

Inventory before the last move. Right now you have: a /chat endpoint that accepts JSON and echoes it, a validation layer that rejects malformed requests with precise 422s, and living documentation for all of it. One invisible problem remains, and it's cheaper to fix now than to discover later.

Browsers enforce a rule your terminal doesn't: JavaScript loaded from one website may not quietly call a different one. "Different" is strict; it's the scheme + domain + port trio, called an origin, so http://localhost:3000 (your future frontend) and http://localhost:8000 (this backend) count as two different websites. In Part 4, the moment your frontend calls fetch("http://localhost:8000/chat"), the browser will check whether the backend has explicitly welcomed that origin, and by default the answer is no: the request gets blocked mid-flight with a console error mentioning CORS (Cross-Origin Resource Sharing).

The welcome mat is a piece of backend middleware. Two additions to app/main.py, an import and a block right under app = FastAPI():

from fastapi.middleware.cors import CORSMiddleware  # new, next to the other imports

app = FastAPI()  # you already have this line

app.add_middleware(  # new, directly below it
    CORSMiddleware,
    allow_origins=["http://localhost:3000"],
    allow_methods=["*"],
    allow_headers=["*"],
)

Read as a sentence: requests from the origin http://localhost:3000 are welcome, any method, any headers. The wildcards are fine between your own two localhost servers; in Part 8, when this goes public, the origin list gets pinned to your real frontend URL.

No frontend exists yet, but you can still prove the door is open, because the browser's permission check is itself an HTTP request: before a cross-origin POST, the browser first sends an OPTIONS request asking "may I?" You can impersonate it from your second terminal:

curl -i -X OPTIONS http://localhost:8000/chat -H "Origin: http://localhost:3000" -H "Access-Control-Request-Method: POST"

HTTP/1.1 200 OK
access-control-allow-methods: DELETE, GET, HEAD, OPTIONS, PATCH, POST, PUT
access-control-max-age: 600
access-control-allow-origin: http://localhost:3000

(Trimmed of the usual date/server headers.) That last header is the yes. When Part 4's frontend knocks for real, the answer is already waiting.

The commit, from the project root, in any terminal that isn't hosting the server:

git add .
git commit -m "part 2: /chat echoes, validates, and documents itself"

Right now the reply is your own words with a sticker on them. In Part 3, LangGraph wires /chat to a real language model, and for the first time the bot says something you didn't.
